SVF EV Series Plastic Tube Variable-Area Flow Meter for Versatile Positioning

SVF EV series plastic tube variable-area flow meter is a variable area flow meter, its main material is polycarbonate (PC) or polysulfone (PSU), so it has excellent high temperature resistance and corrosion resistance. The unique spring design allows the flowmeter to be placed at any angle without affecting accuracy, and the red flow card label is easy to use and identify, making it the most readable flow meter among similar products.

Specifications
Working Principle
Structure
Video

Specification

Table 1: SVF EV Series Plastic Tube Variable-Area Flow Meter Specifications
Model	Measurement Range				Operating Pressure (MPa)	Operating temperature (°C)	Accuracy (±%)	Interface Thread	Interface Material
	20 °C Water		20 °C Air: 101325 Pa
	GPM	LPM	GPM	LPS
SF EV15, SF EV20, SF EV25	0.5–5, 1–7, 1–10, 1–16, 3–18, 4–28	2–20, 4–26, 4–35, 5–60, 15–65, 20–100	80–320, 160–480, 240–720, 320–1100	5–20, 10–30, 15–45, 20–70	≤1	Polycarbonate: 0–80 °C, Polysulfone: 0–120 °C	±6	NPT 1/2", BSPT 1/2", BSP 1/2" M/F, NPT 3/4", BSPT 3/4", BSP 3/4" M/F, NPT 1", BSPT 1", BSP 1" M/F	Brass, Stainless Steel, PP, PVC
SF EV40, SF EV50	3–25, 5–50, 8–80, 10–100	12–90, 20–200, 30–280, 40–380	250–1500, 350–2200, 450–4500	15–95, 20–140, 25–275	≤1	Polycarbonate: 0–80 °C, Polysulfone: 0–120 °C	±6	NPT 1-1/2", BSPT 1-1/2", BSP 1-1/2" F, NPT 2", BSPT 2", BSP 2" F	Brass, Stainless Steel, PP, PVC
